NovaStar VX600 All in One Controller

NovaStar VX600 All in One Controller

NovaStar VX600, an all-in-one controller that integrates video processing and video control into one box. Ideal for ultra-wide and ultra-high LED screens.

Les merShow less

Varenummer:

VX600

Merke:

Beskrivelse

NovaStar VX600 is an all-in-one controller that integrates video processing and video control into one box. It features 6 Ethernet ports and supports video controller, fiber converter and Bypass working modes. A VX600 unit can drive up to 3.9 million pixels, with the maximum output width and height up to 10,240 pixels and 8192 pixels respectively, which is ideal for ultra-wide and ultra-high LED screens.

The VX600 is capable of receiving a variety of video signals and processing high-resolution images. In addition, the device features stepless output scaling, low latency, pixel-level brightness and chroma calibration and more, to present you with an excellent image display experience.

What's more, the VX600 can work with NovaStar's supreme software NovaLCT and V-Can to greatly facilitate your infield operations and control, such as screen configuration, Ethernet port backup settings, layer management, preset management and firmware update.

Les merShow less

Produktdetaljer

Referanse VX600

Sammenligningstabell

NovaStar Video Controller Comparison

Model	VX4S-N	VX400	VX600	VX1000	NovaPro UHD Jr
Loading Capacity (pixel)	2,300,000	2,600,000	3,900,000	6,500,000	10,400,000
Video Source Depth	8bit	8bit	8bit	8bit	8 / 10 / 12bit
Maximum Input	Max Width: 3840x657@60Hz Max Height: 1246x1920@60Hz Min: 800x600@60Hz	Max Width: 3840x648@60Hz Max Height: 800x2784@60Hz Min: 800x600@60Hz	Max Width: 3840x600@60Hz Max Height: 800x2784@60Hz Min: 800x600@60Hz	Max Width: 4096x1136@60Hz Max Height: 1060x3981@60Hz Min: 800x600@60Hz	Max Width: 8192x1080@60Hz Max Height: 1080x8192@60Hz Min: 800x600@60Hz
Maximum Output	Max Width:3840 Max Height:1920	Max Width:10240 Max Height:8192	Max Width:10240 Max Height: 8192	Max Width:10240 Max Height: 8192	Max Width: 16384 Max Height: 8192
Video Input	1x HDMI 1x DVI 1x VGA 1x CVBS 1x DP 1x SDI	2x HDMI1.3 1x DVI 1x 3G-SDI 1x 10G optical fiber port(OPT1)	2x HDMI1.3 1x DVI 1x 3G-SDI 1x 10G optical fiber port(OPT1)	2x HDMI1.4 2x DVI 1x 3G-SDI 1x 10G optical fiber port(OPT1)	1x HDMI2.0 4x DVI 1x DP1.2 2x 12G SDI
Output	4x Network Port 1x DVI LOOP 1x SDI LOOP 1x DVI Monitor	4x Network Port 1x DVI LOOP 1x SDI LOOP 1x HDMI1.3 (Monitor) 1x 10G optical fiber port(OPT2)	6x Network Port 1x HDMI1.3 LOOP 1x DVI LOOP 1x SDI LOOP 1x HDMI1.3 (Monitor) 1x 10G optical fiber port(OPT2)	10x Network Port 1x HDMI1.4 LOOP 1x DVI LOOP 1x SDI LOOP 1x HDMI1.3 (Monitor) 1x 10G optical fiber port(OPT2)	16x Network Port 4x 10G Fiber Output 2x 12G SDI LOOP 1x HDMI2.0 LOOP 1x HDMI (Monitor)
Splicing Loading Capacity	Yes	Yes	Yes	Yes	Yes
Max Layers	2	2	3	3	3
Max Presets	10	10	10	10	10
Knob Brightness Adjustment	Yes	Yes	Yes	Yes	Yes
USB Disk Play On Board	No	No	No	No	No
Control Method	USB, TCP/IP	USB, TCP/IP	USB, TCP/IP	USB, TCP/IP	USB, TCP/IP,RS232
Control Protocol	TCP/IP	TCP/IP	TCP/IP	TCP/IP	TCP/IP
Control Software	NovaLCT	NovaLCT / V-Can	NovaLCT / V-Can	NovaLCT / V-Can	NovaLCT / V-Can

Spesifikasjon

VX600-All-in-One-Controller-Specifications-V1-7-0.pdf
